Page 160: Performance data sd chch
Technical Data SD CHCH Units
Performance Data SD CHCH
Chilled water inlet and outlet temperatures
Model
Air On
5 / 10 °C
7 / 12 °C
8 / 14 °C
10 / 16 °C
Temp. (°C)
TC
SC
TC
SC
TC
SC
TC
SC
/ %RH
(kW)
(kW)
(kW)
(kW)
(kW)
(kW)
(kW)
(kW)
22 / 50
83.0
75.5
63.4
63.4
51.4
51.4
37.6
37.6
SD18D085-CHCH-0
24 / 45
95.6
86.9
75.2
75.2
64.3
64.3
52.4
52.4
26 / 40
106.2
98.2
86.6
86.6
76.3
76.3
65.0
65.0
22 / 50
114.2
98.4
83.9
83.9
71.1
71.1
55.8
55.8
SD22D105-CHCH-0
24 / 45
130.2
112.3
98.3
98.3
86.2
86.2
71.8
71.8
26 / 40
143.8
126.3
112.3
112.3
100.7
100.7
86.6
86.6
22 / 50
147.6
124.3
109.4
105.1
91.6
91.6
73.1
73.1
SD25D135-CHCH-0
24 / 45
175.0
151.2
128.4
121.0
110.0
110.0
92.2
92.2
26 / 40
184.1
159.1
145.4
138.9
127.9
127.9
110.4
110.4
22 / 50
171.4
155.9
130.7
130.7
106.3
106.3
78.4
78.4
SD31D165-CHCH-0
24 / 45
197.3
179.3
155.0
155.0
132.7
132.7
108.3
108.3
26 / 40
218.9
202.7
178.5
178.5
157.4
157.4
134.1
134.1
22 / 50
207.7
184.4
156.0
156.0
130.3
130.3
100.7
100.7
SD35D195-CHCH-0
24 / 45
237.3
211.3
183.6
183.6
159.6
159.6
131.9
131.9
26 / 40
262.6
238.2
210.5
210.5
187.5
187.5
160.7
160.7
SmartCool™ 6 - 200kW
Precision Air Conditioning
160
SmartCool 6 - 200kW Chilled Water Technical Manual 7674716 V1.1.0_04_2014
