Technical Data SD CL00 Units
Electrical Data
SD31D235-CL00
SD31D235-CL00-0
SD31D235-CL00-1
SD31D235-CL00-2
Unit Data - Full Function
(1)
Nominal Run Amps
A
94.7
94.1
170.0
Recommended Mains Fuse Size
A
125
125
200
Unit Data - Cooling Only
Nominal Run Amps
A
18.7
18.7
32.0
Recommended Mains Fuse Size
A
25
25
40
Max Mains Incoming Cable Size
mm²
70
70
185
Mains Supply
V
400V / 3PH + N / 50Hz
380V / 3PH + N / 60Hz
220V / 3PH / 60Hz
Control Circuit
VAC
24
24
24
Evaporator Fan - Motor - Per Fan
Motor Type
EC
EC
EC
Quantity x Motor Size
(2) kW
4 x 2.9
4 x 2.9
4 x 2.9
Full Load Amps
A
4.5
4.5
7.5
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
4
4
4
Number of Elements
12
12
12
Rating
kW
30.0
27.1
30.0
Current Per Phase
A
43.4
41.2
78.8
Humidifier
Capacity
kg/hr
30
30
30
Rating
kW
22.5
22.5
22.5
Full Load Amps
A
32.6
34.2
59.2
(1) Values given for full function units with standard selections for heating, humidification, supply air fans.
(2) Stated motor power is based on maximum electrical power absorbed
