Switched voltage: 5 V
Switched current: 1 mA
Optocoupler input
For active control signals.
Nominal voltage: 24 V DC, external supply
Logic ‘0’: -3...5 V
Logic ‘1’: 15...30 V
Current demand: max. 6 mA
OUTPUTS
SURVEY OF OUTPUTS
* All logic signals can be ”OR-linked”.
RELAY OUTPUTS OUT1, OUT2, OUT3
Contact type: normally open *
Max. contact rating: 500 VA, 250 V, 2A resistive load, 48...62 Hz,
Min. contact rating: 6V, 1 mA DC
Swithing cycles (elec-
trical
):
for I= 1A/2A:
? 800.000 / 500.000
(at ~ 250V (resistive load))
* Versions with two relays OUT1 & OUT2 have a common terminal.
Note:
If the relays OUT1, 2 and 3 are used to operate external
contactors, these must be fitted with RC snubber circuits to
manufacturer specifications to prevent excessive voltage peaks at
switch-off.
OPTOCOUPLER OUTPUTS OUT1, OUT2
(OPTIONAL)
Galvanically isolated optocoupler outputs. Grounded load:
common ‘plus’ control voltage
Switch rating: 18...32 V DC; max. 70 mA
Internal voltage drop: ß 1 V at Imax
Built-in protective circuits:
for short circuit, wrong polarity
Note:
A protective diode for inductive loads must be fitted externally.
OUT3 UNIVERSAL OUTPUT
Galvanically isolated from the inputs. Parallel current/voltage
output with common ‘minus’ terminal (combined use only in
galvanically isolated circuits).
Freely scalable
Resolution:
14 bits
Tracking error I/U: ß 2%
Residual ripple: ß_1%
Ripple (related to span end): 0...130kHz
Current output
0/4...20 mA, configurable, short-circuit proof.
Control range: -0.5...23 mA
Load: ß700 W
Load effect: ß 0.02%
Resolution: ß 1.5 µA
Error: ß 0.1%
Voltage output
0/2...10V, configurable, not permanently short-circuit proof
Control range: -0.15...11.5 V
Load:
³ 2 kW
Load effect: ß 0.06%
Resolution:
ß 0.75 mV
Error: ß 0.1%
Additional error when ß 0.09%
OUT3 as transmitter supply
using simultaneously the current output
Output:
22 mA / ³ 13 V DC
OUT3 as logic signal
Load ß 700
W
0/ß 23 mA
Load > 500
W
0/> 13 V
Technical data
KS 45 71
