Name
Value range Description
SP.2
2nd setpoint
0
interface only
2
di1 switches
5
Func switches
7
Limit 1 switches
8
Limit 2 switches
9
Limit 3 switches
SP.E
external setpoint
0
interface only
1
always on
2
di1 switches
5
Func switches
7
Limit 1 switches
8
Limit 2 switches
9
Limit 3 switches
Y2
2nd actuator value
0
interface only
2
di1 switches
5
Func switches
7
Limit 1 switches
8
Limit 2 switches
9
Limit 3 switches
mAn
automatic/manual switching
0
interface only
1
always on
2
di1 switches
5
Func switches
7
Limit 1 switches
8
Limit 2 switches
9
Limit 3 switches
C.oFF
controller off
0
interface only
2
di1 switches
5
Func switches
7
Limit 1 switches
8
Limit 2 switches
9
Limit 3 switches
Err.r
Reset error list
0
interface only
2
di1 switches
7
Limit 1 switches
8
Limit 2 switches
9
Limit 3 switches
P.run
program run/stop
0
interface only
2
di1 switches
5
Func switches
7
Limit 1 switches
8
Limit 2 switches
9
Limit 3 switches
I.ChG
switchover Inp1/ Inp2/ di1
0
interface only
2
di1 switches
7
Limit 1 switches
8
Limit 2 switches
9
Limit 3 switches
fDI1
forcing of the digital input (only visible with BlueControl
Ò
!)
0
not active
1
the value for this analog input is defined via interface.
Configuration level
Configurations
58
KS 45
