10.2 Configurations
Dependent on device version und adjusted configurations values not needed become hidden.
µ Entrys marked with this symbol are selectable only with existing device-option.
Controller Cntr
Name Value range Description
SP.Fn
setpoint processing
0 Setpoint/ ext. Setpoint
1 program controller
2 timer mode 1
3 timer mode 2
4 timer mode 3
5 timer mode 4
6 timer mode 5
7 timer mode 6
8 standard + SP-E
9 programmer + SP.E
b.ti
0...9999 timer tolerance
C.tYP process value processing
µ
0 process value = x1
1 ratio controller (x1+oFFS)/x2
2 difference (x1 - x2)
3 max (x1, x2)
4 min (x1, x2)
5 mean value (x1, x2)
6 Switch-over (x1, x2)
7 Oxygen measurement with const. probe temperature
8 Oxygen measurement with measured probe temperature
C.Fnc control behaviour
0 signaller (on/off controller)
1 PID controller (2-point and continuous)
2 D/Y switch-over
3 2 x PID (3-point and continuous)
4 3-point stepping controller
mAn automatic/manual switching
0 Manual operation not permitted
1 Manual operation admitted
C.Act direction of operation
0 inverse, e.g. heating
1 direct, e.g. cooling
FAIL behaviour at sensor break
0 outputs off
1 switch to Y2
2 mean correcting value
rnG.L
lower control range [phys]
rnG.H upper control range [phys]
Adt0
Tuning of cycle time
0 automatische Optimierung
1 keine Optimierung
Configuration level
Configurations 54 KS 45
