Limits Lim1...Lim3
Name
Value range
Description
Fnc.1
(Fnc.2)
(Fnc.3)
function of limit 1 (2, 3)
0
switched off
1
measurement value
2
measurement value with latch
Src.1
(Src.2)
(Src.3)
source of limit 1 (2, 3)
0
process value
1
control deviation
2
deviation + suppression
3
INP1
4
INP2
6
Setpoint
7
output value
11
deviation + suppression without time limit
HC.AL
heating current alarm
0
switched off
1
overload + short circuit
2
break + short circuit
LP.AL
loop alarm
0
no LOOP alarm
1
LOOP alarm active
C.Std
OFF; 1 …
9999999
Control operating hours (only visible with BlueControl
Ò
!)
C.Sch
OFF; 1 …
9999999
Control alternation number (only visible with BlueControl
Ò!)
Outputs Out.1, Out.2, Out.3,(relay/analog)
µ
Name
Value range
Description
O.tYP
type of OUT (only Out.3 - analog)
µ
0
relay/logic
1
0 ... 20 mA continuous
2
4 ... 20 mA continuous
3
0 ... 10 V continuous
4
2 ... 10 V continuous
5
transmitter supply
O.Act
direction of operation
0
direct
1
inverse
Y.1
controller output Y1
0
not active
1
active
Y.2
controller output Y2
0
not active
1
active
Lim.1
signal limit 1
0
not active
1
active
Lim.2
signal limit 2
0
not active
1
active
Lim.3
signal limit 3
0
not active
1
active
LP.AL
loop alarm
0
not active
1
active
HC.AL
heating current alarm
0
not active
1
active
Configuration level
Configurations
