Inp.1r S.tYP
41 special ( -2,5...115 mV)
42 special ( -25...1150 mV)
43 special ( -25...90 mV)
44 special ( -500...500 mV)
47 special ( -200...200 mV)
These high-impedance inputs are without break monitoring. If necessary, input signal monitoring is possible via the
limit values.
Further recommendations for adjustment:
g
Input 1 must be operated without linearization:
Inp.1r S.Lin 0 no linearization
g
With O 2 measurement, specification if parameters related to the measured value should be output in ppm
or % is required. This is done centrally during configuration.
othrr O2 0 Unit: ppm
1 Unit: %
g
Whether the temperature of the non-heated
l probe is entered in °C, °F or K can be selected during
configuration.
othrr Unit 1 °C
2 °F
3 K
Displays
With configuration for O
2
measurement (see above), the oxygen
content is displayed as process value with the selected unit (see
above) on line 1. Max. 4 characters can be displayed.
With display range overflow, “ EEEE” is displayed .
Example: the ppm range is selected, but the value is a % value.
When exceeding the display span start, 0 is displayed.
+ Tip: the unit can be displayed on line 2.
Functions
O 2 measurement (optional) 26 KS 45
20.95
üû/o
