Name Value range Description
ICof Block controller off (only visible with BlueControl
Ò
!)
0 Released
1 Blocked
IAda Block auto tuning (only visible with BlueControl
Ò
!)
0 Released
1 Blocked
ILat Block error memory (only visible with BlueControl
Ò
!)
0 Released
1 Blocked
IExo Block extended operating level (only visible with BlueControl
Ò
!)
0 Released
1 Blocked
Pass OFF...9999 Password (only visible with BlueControl
Ò
!)
IPar Block parameter level (only visible with BlueControl
Ò
!)
0 Released
1 Blocked
ICnf Block configuration level (only visible with BlueControl
Ò
!)
0 Released
1 Blocked
ICal Block calibration level (only visible with BlueControl
Ò
!)
0 Released
1 Blocked
T.Dis2 Settings for text in display 2 (max. 5 digits)
(only visible with BlueControl
Ò
!)
Linearization Lin
only visible with BlueControl
Ò
!
Name Value range Description
U.LinT Temperature unit of the linearization table
0 without unit
1 in Celsius
2 in Fahrenheit
3 in Kelvin
In.1 … In.16 OFF (ab In.3)
-1999...9999
input 1 … input 16
Ou.1 … Ou.16 -999.0 … 9999 output 1 … output 16
Depending on equipment version and the configuration unused parameters are hidden.
g
Value U.LinT defines the unit of input values specified for linearization of temperature values. Value entry
in Celsius despite display of the measured value in Fahrenheit is possible.
w
Specify the input signals mV, V, mA, % or Ohm dependent on input type.
w
For special thermocouples (S.tYP = 18), specify the input values in
mV and the output values in the
temperature unit adjusted in U.LinT.
w
For special resistance thermometer (KTY 11-6) (S.tYP = 23), specify the input values in Ohm and
the output value in the temperature unit adjusted in U.LinT .
g
Resetting to factory setting (default)
r chapter 15.4
Configuration level
Configurations 60 KS 45
