11.2 Parameters
µ Entrys marked with this symbol are selectable only with existing device-option.
Controller Cntr
Name Value range Description
Pb1 1...9999 proportional band 1 [phys]
Pb2
1...9999 proportional band 2 [phys]
ti1
off, 1...9999 integral action 1 [s]
ti2 off, 1...9999 integral action 2 [s]
td1
off, 1...9999 derivative action 1 [s]
td2
off, 1...9999 derivative action 2 [s]
t1 0,4...9999 min. cycle time 1 [s]
t2
0,4...9999 min. cycle time 2 [s]
SH 0..9999 neutral zone [phys]
d.SP
-1999...9999 additional contact D / Y [phys]
tP
off, 0.1...9999 min. pulse length [s]
tt 3...9999 motor travel time [s]
Y2
-100...100 correcting variable 2
Y.Lo
-105..105 lower output range [%]
Y.Hi -105...105 upper output range [%]
Y.0
-105...105 working point [%]
Ym.H
-100...100 max. mean value [%]
L.Ym 1...9999 max. deviation mean [phys]
oFFS
-120...120 ratio offset
tEmP 0...9999 probe temperature
µ
Setpoint SEtP
Name Value range Description
SP.LO -1999...9999 lower setpoint range [phys]
SP.Hi
-1999...9999 upper setpoint range [phys]
SP.2
-1999...9999 2nd setpoint [phys]
r.SP off,0.01...9999 setpoint ramp [/min]
t.SP
0.0...9999 timer dwell time [min]
Programmer ProG
Name Value range Description
SP.01
-1999...9999 target setpoint 1
Pt.01 0.0...9999 segment time 1 [min]
SP.02
-1999...9999 target setpoint 2
Pt.02
0.0...9999 segment time 2 [min]
SP.03 -1999...9999 target setpoint 3
Pt.03
0.0...9999 segment time 3 [min]
SP.04
-1999...9999 target setpoint 4
Pt.04 0.0...9999 segment time 4 [min]
Inputs InP.1, InP.2
Name Value range Description
InL.1
(Inl.2)
-1999...9999 lower input value [phys]
Oul.1
(OuL.2)
-1999...9999 lower output value [phys]
InH.1
(InH.2)
-1999...9999 upper input value [phys]
OuH.1
(OuH.2)
-1999...9999 upper output value [phys]
