-26-
6.2.2 RS232C Communication Commands
Typical Host -> FGV commands.
"cr"means carriage return.
Commands Content Response Explanation of Response
AA cr Tare AA cr Tare
AB cr Cancel data transmission AB cr Cancel data transmission
AC cr Switch to positive peak mode AC cr Switch to positive peak mode
AD cr Switch to standard measuring mode AD cr Switch to standard measuring mode
AL cr Switch to negative peak mode AL cr Switch to negative peak mode
AE cr Clear peak values AE cr Clear peak values
AF cr Switch unit to Kg, g AF cr Switch unit to Kg, g
AG cr Switch unit to N AG cr Switch unit to N
AH cr Switch unit to lb AH cr Switch unit to lb
AK cr Switch unit to oz AK cr Switch unit to oz
BA cr Request current measurement BA cr NA xxxxxx cr
xxxxxx: Polarity, decimal point, 4 digit value
BB cr
Request continuous transmission of
measurement data (10 times/second)
BB cr NA xxxxxx cr
BB1 cr
Request continuous transmission of
measurement data (20 times/second)
BB1 cr NA xxxxxx cr
BB2 cr
Request continuous transmission of
measurement data (50 times/second)
BB2 cr NA xxxxxx cr
BB3 cr
Request continuous transmission of
measurement data (100 times/second)
BB3 cr NA xxxxxx cr
BC cr Transmission request of model BC cr NE xx cr
xx: 2-digit number indicating model
02: FGV-0.5, 03: FGV-1, 04: FGV-2, 05: FGV-5, 06: FGV-10,
07: FGV-20, 08: FGV-50, 09: FGV-100, 1A: FGV-200
BD cr Transmission request of unit BD cr NH x cr
x: one-digit number indicating unit
0: N, 1: kg, 2: g, 3: lb, 4: oz
BE cr Transmission request of plus peak value BE cr NB xxxxxx cr
xxxxxx: Polarity, decimal point, 4 digit value
BF cr Transmission request of minus peak value BF cr NC xxxxxx cr
If the FGV-XY detects a communication error,
the following error codes are sent.
OB cr Format error (Command error)
OF cr Flaming error
OH cr Overrun error
