CARGOMASTER®5

Operators Manual - 56

Select the font size drop down menu (between the group selector and the unit
selector) from the Info line.

Or:

Hold down the CTRL key and press + or - on the numeric keypad

This also applies for the ValueTable and TankPlan pictures

Screenshot 36 The Info-line

Line/Vapors

CARGOMASTER® provides two windows for monitoring

Line

and

Vapor

pressures.

Shift

opens the Line Pressure window, while

Ctrl

opens the

Vapor Pressure window. Both windows can also be accessed from the Misc
menu.

In each window, the Sum fields allow for input of alarm limits, and for
enabling/disabling alarms. As for any other alarms, ON or OFF or simply 1 or
0 can be entered to enable / disable.

In the Line Pressure window you can select whether to see all line pressures
installed or just those with a pressure of more than 0.5Bar or less than –0.5Bar
(Automatic).

Both windows also have a setting called Service, which shows the actual
sensor data, like pressure, gain and temperature.

Screenshot 37 The Line Pressure window.

Note: No adjustments to gain settings can be made here

Keyboard shortcuts

CARGOMASTER® has quite a few keyboard shortcuts built in. The shortcuts
save a lot of menu clicking and navigation when you first get to know them.
Shortcuts are combinations of keys pressed simultaneously on the keyboard.

CTRL

is such a shortcut. This means pressing down and holding the

CTRL key and then pressing (and releasing) the F3 key. After releasing the F3
