CARGOMASTER®5
Operators Manual - 12
Selecting view
CARGOMASTER® offers three different ways to view data. They are
accessed either by keyboard shortcuts, or by selecting the Pictures button in
the bottom of the screen. Select one of the following:
TankPlan – Graphical tank layout, with color
coding of groups
ValueTable – Numeric spreadsheet, pure
numbers only
BarGraph – Vertical bars representing levels,
volumes etc.
Table 1 Shortcuts for view selection
Click the view you want, or use the shortcuts. E.g. Shift+F3 means holding
down the
SHIFT key and then pressing, and releasing, the F3 key.
Note that there are two of each Shift , Ctrl or Alt keys - only the left Alt key
will work with this while all Shift and Ctrl keys will work.
