5
START-UP
46
OPTIBAR PC 5060 C
www.krohne.com 04/2014 - 4003437201 - MA OPTIBAR PC 5060 C R01 en
5.4.4 Additional adjustments
5.4.5 Info
PIN In this menu item the PIN can be changed. This option is only available if it has been enabled under
"Setup - Lock adjustment". The PIN is "0000" by default factory conditions.
0000 Change PIN
Date / Time Internal clock setting
Write date, time, data in device
Reset For further information refer to Reset on page 47.
Delivery status and Basic settings
Copy instrument
settings
For further information refer to Saving the device settings on page 48.
Copy instrument settings
Special
parameters
Changing these settings is possible only after consultation with a service employee.
Scaling In menu item "Scaling variable" you define the scaling variables and the scaling unit for the level
mode.
In menu item "Scaling format" you define the scaling format on the display and the scaling of the
level measurement for 0% and 100%.
Scaling variable Scaling variable
Scaling unit
Scaling format Scaling format
100% corresponds - user-defined value
0% corresponds - user-defined value
Current output In this menu item it is determined which measured variable relates to which current output. Under
"Current output - Adjustment", the current output can be assigned a corresponding measured
value.
Current output
variable
For applications "Level"
Filling height or Process pressure (Adjustment units), Percent, Scaled,
Linear percent, Meas. cell temp. and Electronics temperature
For applications "Process pressure"
Process pressure, Percent, Linear percent, Meas. cell temp. and
Electronics temperature
Current output,
adjustment
0% = 0% or 100% = 100%
HART ® mode The pressure transmitter offers the HART ® modes "Analogue current output" and "Fix current (4
mA). Under "Fix current (4 mA)", up to 64 sensors can be operated on a two-wire multidrop mode.
Each device must be assigned a HART
® address between 0 und 63. The analogue signal is fixed at 4
mA. Under "Analogue current output", however, a 4…20 mA signal can also be issued for the
assigned HART
® address in multidrop mode.
HART ® address 0...63
Output mode Analogue current output with HART ® or Fix current (4 mA) with HART ®
Device name Device name
Serial number
Instrument version Software version
Hardware version
Factory calibration Factory calibration date
Date of last change
Sensor characteristics Order-related device characteristics
