Electrical connections – KROHNE OPTIBAR PC 5060 C EN User Manual
Page 36
4
ELECTRICAL CONNECTIONS
36
OPTIBAR PC 5060 C
www.krohne.com
04/2014 - 4003437201 - MA OPTIBAR PC 5060 C R01 en
4.3.3 Single chamber housing
The following illustration applies to both the non-Ex as well as the Ex ia, the Ex d and the Ex d ia
version.
DANGER!
For devices used in hazardous areas, additional safety notes apply; please refer to the Ex
documentation.
Electronics compartment
1 Power supply / signal output
2 Interface adapter for the display and adjustment module
3 Digital interface
4 Ground terminal for connection of the cable shield
.book Page 36 Friday, May 2, 2014 12:49 PM
