OPERATION
4
45
GFC 300
www.krohne.com 07/2012 - 4001866001 - AD GFC 300 FF R01 en
P_T_INPUTS P_T_INPUTS P_T_INPUTS P_T_INPUTS
P & T inputs
R/W (Fct. C1.12) fixed
Settings:
automatic / fixed
PIPE_PRESSURE PIPE_PRESSURE PIPE_PRESSURE PIPE_PRESSURE
pipe pressure
R/W Input of a single value of the pipe pressure for compensation
of the expansion by pressure (Fct. C1.14).
1.01325e -5
Settings:
0.0...250.00
PIPE_ PIPE_ PIPE_ PIPE_
TEMPERATURE TEMPERATURE TEMPERATURE TEMPERATURE
pipe temperature
R/W Input of operational temperature for correction of the thermal
expansion (Fct. C1.13).
20.0
Settings:
-40.0…800.0
TRANSDUCER_ TRANSDUCER_ TRANSDUCER_ TRANSDUCER_
DIRECTORY DIRECTORY DIRECTORY DIRECTORY
Transducer
Directory Entry
A directory that specifies the number and starting indices of
the data collections in the transducer block.
0
TRANSDUCER_ TRANSDUCER_ TRANSDUCER_ TRANSDUCER_
TYPE TYPE TYPE TYPE
Transducer Type
R Identifies the transducer that follows. Other
XD_ERROR XD_ERROR XD_ERROR XD_ERROR
Transducer Error
One of the transducer error codes defined in the FF
Transducer Specifications in section "4.7 Block Alarm
Subcodes".
Uninitialized
Settings:
• 16: Unspecified error
• 17: General error
• 18: Calibration error
• 19: Configuration error
• 20: Electronics Failure
• 21: Mechanical Failure
• 22: I/O Failure
• 23: Data Integrity Error
• 24: Software Error
• 25: Algorithm Error
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
