KROHNE GFC 300 FOUNDATION FIELDBUS - Manual (Page 14)

4
OPERATION
14
GFC 300
www.krohne.com 07/2012 - 4001866001 - AD GFC 300 FF R01 en
LIM_NOTIFY LIM_NOTIFY LIM_NOTIFY LIM_NOTIFY
Limit Notify Limit Notify Limit Notify Limit Notify
R/W Maximum number of unconfirmed alert notify messages
allowed.
20
Setting:
0...255
MANUFAC_ID MANUFAC_ID MANUFAC_ID MANUFAC_ID
Manufacturer ID Manufacturer ID Manufacturer ID Manufacturer ID
R Manufacturer identification number - used by an interface
device to locate the DD file for the resource.
KROHNE
Setting:
KROHNE
MAX_NOTIFY MAX_NOTIFY MAX_NOTIFY MAX_NOTIFY
Maximum Notify Maximum Notify Maximum Notify Maximum Notify
R Maximum number of unconfirmed alert notify messages
possible.
20
Setting:
0...255
MEMORY_SIZE MEMORY_SIZE MEMORY_SIZE MEMORY_SIZE
Memory Size Memory Size Memory Size Memory Size
R Available configuration memory in the empty resource. To be
checked before attempting a download.
0
MIN_CYCLE_T MIN_CYCLE_T MIN_CYCLE_T MIN_CYCLE_T
Minimium Cycle Time Minimium Cycle Time Minimium Cycle Time Minimium Cycle Time
R Time duration of the shortest cycle interval of which the
resource is capable (in [1/32 ms]).
6400
NV_CYCLE_T NV_CYCLE_T NV_CYCLE_T NV_CYCLE_T
Nonvolatile Cycle Nonvolatile Cycle Nonvolatile Cycle Nonvolatile Cycle
Time Time Time Time
R Interval between writing copies of NV parameters to non-
volatile memory. Zero means never (in [1/32 ms]).
256000
RESTART RESTART RESTART RESTART
Restart Restart Restart Restart
R/W Allows a manual restart to be initiated. Several degrees of
restart are possible. They are 1: Run, 2: Restart resource, 3:
Restart with defaults and 4: Restart processor.
Run
Setting:
Uninitialized / Run / Resource / Defaults / Processor
RS_STATE RS_STATE RS_STATE RS_STATE
Resource State Resource State Resource State Resource State
R State of the function block application state machine. Standby
Setting:
Uninitialized / Start_Restart / Initialization / Online Linking /
Online / Standby / Failure
SET_FSTATE SET_FSTATE SET_FSTATE SET_FSTATE
Set Fault State Set Fault State Set Fault State Set Fault State
R/W Allows the fault state condition to be manually initiated by
selecting "Set".
Off
Setting:
Off
SHED_RCAS SHED_RCAS SHED_RCAS SHED_RCAS
Shed Remote Cascade Shed Remote Cascade Shed Remote Cascade Shed Remote Cascade
R/W Time duration at which to give up on computer writes to
function block RCAS locations.
640000
Setting:
0...4294967295 in [1/32 ms]
SHED_ROUT SHED_ROUT SHED_ROUT SHED_ROUT
Shed Remote Out Shed Remote Out Shed Remote Out Shed Remote Out
R/W Time duration at which to give up on computer writes to
function block ROUT locations.
640000
Setting:
0...4294967295 in [1/32 ms]
TEST_RW TEST_RW TEST_RW TEST_RW
Test R Write Test R Write Test R Write Test R Write
Read/write test parameter - used only for conformance
testing.
Note: Subelements "1..15" have no function!
-
UPDATE_EVT UPDATE_EVT UPDATE_EVT UPDATE_EVT
Update Event Update Event Update Event Update Event
This alert is generated by any change to the static data. -
Unacknowledged R/W A discrete enumeration which is set to "Unacknowledged"
when an update occurs, and set to "Acknowledged" by a write
from a human interface device or other entity which can
acknowledge that the alarm/event has been noticed.
Uninitialized
Setting:
Uninitialized / Acknowledged / Unacknowledged
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
