4
OPERATION
32
GFC 300
www.krohne.com 07/2012 - 4001866001 - AD GFC 300 FF R01 en
UNITS_INDEX
Units Index
R/W Device Description units code index for the engineering unit
descriptor for the associated block value.
m³/h
Settings:
m³/s; m³/min; m³/h; m³/d; L/s; L/min; L/h; L/d; ML/d; kL/min;
kL/h; kL/d; mL/min; CFS; CFM; CFH
DECIMAL
Decimal (Point)
R The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
1
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
TYPE2 TYPE2 TYPE2 TYPE2
Primary Value Primary Value Primary Value Primary Value
Type2 Type2 Type2 Type2
R The type of measurement represented by the primary value.
For example: mass flow, absolute pressure, differential
temperature
Corrected volume
flow
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
2222
corrected volume corrected volume corrected volume corrected volume
flow flow flow flow
The measured gas volume flow value and status available to
the Function Block.
-
STATUS
Status
R Digital transducers, unlike their analogue versions, can detect
faults that make the measurement bad or prevent the
actuator from responding. This additional, valuable
information will be passed along with each transmission of a
data value in the form of a status attribute.
-
VALUE
Value
R A numerical quantity entered by a user or calculated by the
algorithm.
-
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
RANGE_2 RANGE_2 RANGE_2 RANGE_2
corrected volume corrected volume corrected volume corrected volume
flow range flow range flow range flow range
The high and low range limit values, the engineering units
code and the number of digits to the right of the decimal point
to be used to display the Primary Value.
-
EU_100
Engineering Unit
100
R The engineering unit value which represents the upper end of
range of the associated Block Parameter.
NaN
EU_0
Engineering Unit 0
R The engineering unit value which represents the lower end of
range of the associated Block Parameter.
-NaN
UNITS_INDEX
Units Index
R/W Device Description units code index for the engineering unit
descriptor for the associated block value.
Nm³/h
Settings:
SCFM; SCFH; Nm³/s; Nm³/min; Nm³/h; Nm³/d; Sm³/s;
Sm³/min; Sm³/h; Sm³/d; NL/s; NL/min; NL/h; NL/d; SL/s;
SL/min; SL/h; SL/d; MSCFD; MMSCFD
DECIMAL
Decimal (Point)
R The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
0
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
TYPE3 TYPE3 TYPE3 TYPE3
Primary Value Primary Value Primary Value Primary Value
Type3 Type3 Type3 Type3
R The type of measurement represented by the primary value.
For example: mass flow, absolute pressure, differential
temperature
mass flow
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
3333
mass flow mass flow mass flow mass flow
The measured mass flow value and status available to the
Function Block.
-
STATUS
Status
R Digital transducers, unlike their analogue versions, can detect
faults that make the measurement bad or prevent the
actuator from responding. This additional, valuable
information will be passed along with each transmission of a
data value in the form of a status attribute.
-
VALUE
Value
R A numerical quantity entered by a user or calculated by the
algorithm.
-
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
RANGE_3 RANGE_3 RANGE_3 RANGE_3
mass flow range mass flow range mass flow range mass flow range
The high and low range limit values, the engineering units
code and the number of digits to the right of the decimal point
to be used to display the Primary Value.
-
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
