GDB-03 Demo Module User Manual

92

Upgrade firmware

1. Insert a USB flash disk containing the

firmware file,

xxx.upg

into the front panel

USB slot.

2. Remove all probes and cables from the BNC

terminals.

3. Press the Utility key and select File

Utilities from the bottom menu.

4. Rotate the Variable knob to select

the USB directory and then press
the Select key.
