GDB-03 Demo Module User Manual

22

Display Autoset mode (Analog Mode 5)

Step

1. Press the Test key on the front

panel of the GDS-3000.

2. Press the Demo button.

3. Press the Down button to select

Analog Mode 5. A screen
confirming Analog Mode 5 is
selected as shown on the next page
appears.
