Display Pulse Width (Digital Mode 1)

Step

1. Connect the probes to the

terminals marked Digital CH1~
CH4, and grounding clips to
ground terminal ( ).

2. Connect the probes to

corresponding CH1~CH4
terminals on the GDS-3000.

3. Press the Test key on the front

panel of the GDS-3000.

4. Press the Demo button.
