GDB-03 Demo Module User Manual
8
Specifications
Signal output • 5 types for digital analyzer, 9 types for analog
analyzer(For GDS-3000)
• 7 types for digital analyzer, 8 types for analog
analyzer(For GDS-2000A)
• FM signal
• Sin / Square / Triangle Signal
• Video signal
Power supply 5V DC, USB or auxiliary power input
Accessory USB cable type A – type B x 1
Dimensions 13(W)x14.5(H)
Display system Display Mode Passive Matrix
Display Resolution 128x64
Display Color White
Module Size 26.4x28.5x1.26 mm
Panel Size 26.4x19.7x1.26 mm
Camera module PCB size 32x32 mm
CCD sensor 1/4’’ VGA Progressive
Color CMOS Sensor
Video analog Output 720x480I(NTSC) /
720x576I(PAL)
