GETTING STARTED
5
Required tools
• GDS-3000 x 1 or GDS-2000A x 1
• Demo board x 1
• USB type A- type B cable x 1. Used for demo board’s power
• Deep memory: 25k points record length(For GDS-3000)
• Deep memory: 2M points record length(For GDS-2000A)
• Standard oscilloscope probe x 4
• DS2-08LA or DS2-16LA(For GDS-2000A only)
Demonstration type
GDS-3000
• VPO (page16)
• Split window 1 (page 18)
• Split window 2 (page 19)
• Auto Range Function (page 21)
• Autoset mode (page 22)
• XY mode (page 25)
• Gating Measurement (page 27)
• Pulse Runt (page 28)
• Rise Fall (page 30)
• Pulse Width (page 31)
• UART (page 33)
• I 2 C (page 35)
• SPI (page 36)
• Delay(page 38)
• FM (page 40)
• Video (page 42)
GDS-2000A
• Autoset mode (page 55)
• XY mode (page 57)
• Gating Measurement (page 59)
• Pulse Runt (page 60)
• Rise Fall (page 62)
• Search (page 63)
• Segments (page 65)
• Parallel (page 66)
• Pulse Width (page 68)
• Delay (page 70)
• LM(Long Memory)(page 72)
• Logic (page 74)
• UART (page 75)
• I 2 C (page 77)
• SPI (page 78)
• CAN(page 80)
