GDS-2000A

77

Display I

2

C (Digital Mode 6)

Step

1. Press the Test key on the front

panel of the GDS-2000A.

2. Press the Demo button.

3. Press the Down button to select

Digital Mode 6. A screen
confirming Digital Mode 6 is
selected as shown below appears.

4. Press the Run button to display the

waveform.
