GDB-03 Demo Module User Manual

28

Note

You can set the position of the cursors to set the
range of the Gating Measurement.

Display Pulse Runt (Analog Mode 8)

Step

1. Press the Test key on the front

panel of the GDS-3000.

2. Press the Demo button.

3. Press the Down button to select

Analog Mode 8. A screen
confirming Analog Mode 8 is
selected as shown below appears.
