GDS-2000A

75

Display UART (Digital Mode 5)

Step

1. Press the Test key on the front

panel of the GDS-2000A.

2. Press the Demo button.

3. Press the Down button to select

Digital Mode 5. A screen
confirming Digital Mode 5 is
selected as shown below appears.
