GDS-3000

33

Display UART (Digital Mode 2)

Step

1. Press the Test key on the front

panel of the GDS-3000.

2. Press the Demo button.

3. Press the Down button to select

Digital Mode 2. A screen
confirming Digital Mode 2 is
selected as shown below appears.
