GDS-3000

9

G

DS-3000

Demonstration setup

Step

1. Turn on the GDS-3000.

2. Install the Demo module

software. Please refer to the
chapter “SOFTWARE
INSTALLATION” on page 14
for details.

Note

A. Please make sure that the firmware version is

V1.14 or above for models with a bandwidth of
less than or equal to 350MHz.

B. Please make sure that the firmware version is

V1.0 or above for the model with 500MHz.

C. Please refer to the “Appendix” chapter for

information about updating the firmware.

3. Connect the USB cable as shown

in the following diagram to
power up the demo board.
Connect the Type A plug to the
GDS-3000 and the Type B plug
to the demo board.
