GDB-03 Demo Module User Manual

48

G

DS-2000A

Demonstration setup

Step

8. Turn on the GDS-2000A.

9. Install the Demo module

software. Please refer to the
chapter “SOFTWARE
INSTALLATION” on page 53
for details.

Note

A. Please make sure that the firmware version is

V1.09 or above.

B. Please refer to the “Appendix” chapter for

information about updating the firmware.

10. Connect the USB cable as shown

in the following diagram to
power up the demo board.
Connect the Type A plug to the
GDS-2000A and the Type B plug
to the demo board.
