38
M
ODEL
8100 U
SER
/ I
NSTALLATION
M
ANUAL
D
IAGNOSTICS
A
CCESS
I
NSTRUCTIONS
:
1. From the M
AIN
M
ENU
screen, se-
lect D
IAGNOSTICS
.
D
ESCRIPTION
:
The following options will be available
from the Diagnostics screen:
1. Status. This function presents
the status checks on the primary
functional areas of the dispens-
ing mechanism.
3. Test Dispense. This function instructs the dispensing mechanism to dis-
pense one (1) note from the cassette into the reject cassette/vault/com-
partment. A return code in a single cassette dispenser of ‘20 1 0 0 0’
indicates a successful test dispense (20) and (1) note picked from cas-
sette A.
4. Format Graphic Memory. This function erases the memory used to store
AD graphics. AD graphics can then be downloaded from a local terminal
or through Triton Connect.
5. Test Receipt Printer. This function tests the operation of the receipt
printer and prints out configuration parameters, processor setup, etc,
that may be used to verify terminal setup.
6. Version #’s. This function displays the version numbers of the terminal
operating software.
7. More Diagnostics. Accesses additional diagnostic functions.
2. Purge. This function instructs the dispenser to remove all documents
from the feed path. The return code for a successful purge in a single
cassette dispenser is ‘20 20 20’. The return code for a multi-cassette
dispenser is ‘0’.
