FCIP monitoring thresholds
The following tables list the default monitoring thresholds for Fiber Channel over IP (FCIP) criteria used
by MAPS. All actions are triggered when the reported value is greater than the threshold value.
FCIP monitoring thresholds for devices other than the Brocade 7840
Default FCIP monitoring thresholds for devices other than the Brocade 7840 TABLE 23
Monitoring statistic Units
MAPS thresholds and actions per
policy
Actions Aggressive Moderate Conservative
State change
(CIR_STATE) Changes per minute 0 3 5 RASLOG, SNMP,
EMAIL
Utilization percentage
(CIR_UTIL) Percentage per hour 60 75 90 RASLOG, SNMP,
EMAIL
Packet loss
percentage
(CIR_PKTLOSS) Percentage per
minute 0.01 0.05 0.1 RASLOG, SNMP,
EMAIL
FCIP monitoring thresholds for Brocade 7840 devices
Default FCIP monitoring thresholds for Brocade 7840 devices TABLE 24
Monitoring statistic Units
MAPS thresholds and actions per
policy
Actions Aggressive Moderate Conservative
Tunnel (STATE_CHG) Changes per minute 0 1 3 RASLOG, SNMP,
EMAIL
Tunnel QoS (UTIL) Percentage per hour 60 75 90 RASLOG, SNMP,
EMAIL
QoS: Packet loss
percentage
(PKTLOSS) Percentage per
minute 0.01 0.05 0.1 RASLOG, SNMP,
EMAIL
Circuit: Circuit state
(CIR_STATE) Changes per minute 0 3 5 RASLOG, SNMP,
EMAIL, FENCE
Circuit: Utilization
percentage
(CIR_UTIL) Percentage per hour 50 75 90 RASLOG, SNMP,
EMAIL
FCIP monitoring thresholds
