A-44
IM 11M12D01-61E
AI FB DD Menu structure
AI FB (Top menu)
Block Info | ALARM_SUM
| TAG_DESC | | ALARM_SUM.CURRENT
| STRATEGY | | ALARM_SUM.UNACKNOWLEDGED
| ALERT_KEY | | ALARM_SUM.UNREPORTED
Mode Block | | ALARM_SUM.DISABLED
| MODE_BLK.TARGET | ACK_OPTION
| MODE_BLK.ACTUAL | ALARM_HYS
| MODE_BLK.PERMITTED | Hi Hi Alarm
| MODE_BLK.NORMAL | | HI_HI_PRI
Dynamic Variables | | HI_HI_LIM
| FIELD_VAL | | HI_HI_ALM
| | FIELD_VAL.Status | | | HI_HI_ALM.UNACKNOWLEDGED
| | FIELD_VAL.Value | | | HI_HI_ALM.ALARM_STATE
| | | HI_HI_ALM.TIME_STAMP
| PV.Status | | | HI_HI_ALM.SUB_CODE
| | PV.Value | | | HI_HI_ALM.VALUE
| OUT | Hi Alarm
| | OUT.Status | | HI_PRI
| | OUT.Value | | HI_LIM
| TOTAL | | HI_ALM
Configuration | | | HI_ALM.UNACKNOWLEDGED
| Mode Block | | | HI_ALM.ALARM_STATE
| | MODE_BLK.TARGET | | | HI_ALM.TIME_STAMP
| | MODE_BLK.ACTUAL | | | HI_ALM.SUB_CODE
| | MODE_BLK.PERMITTED | | | HI_ALM.VALUE
| | MODE_BLK.NORMAL | Lo Alarm
| CHANNEL | | LO_PRI
| XD_SCALE | | LO_LIM
| | XD_SCALE.EU100 | | LO_ALM
| | XD_SCALE.EU0 | | | LO_ALM.UNACKNOWLEDGED
| | XD_SCALE.UNITS INDEX | | | LO_ALM.ALARM_STATE
| | XD_SCALE.DECIMAL POINT | | | LO_ALM.TIME_STAMP
| OUT_SCALE | | | LO_ALM.SUB_CODE
| | OUT_SCALE.EU100 | | | LO_ALM.VALUE
| | OUT_SCALE.EU0 | Lo Lo Alarm
| | OUT_SCALE.UNITS INDEX | | LO_LO_PRI
| | OUT_SCALE.DECIMAL POINT | | LO_LO_LIM
| PV_FTIME | | LO_LO_ALM
| Options | | | LO_LO_ALM.UNACKNOWLEDGED
| | L_TYPE | | | LO_LO_ALM.ALARM_STATE
| | LOW_CUT | | | LO_LO_ALM.TIME_STAMP
| | IO_OPTS | | | LO_LO_ALM.SUB_CODE
| | STATUS_OPTS | | | LO_LO_ALM.VALUE
| Total Setup | UPDATE_EVT
| | TOTAL_START | | UPDATE_EVT.UNACKNOWLEDGED
| | TOTAL_RATE_VAL | | UPDATE_EVT.UPDATE_STATE
| | TOTAL_RESET | | UPDATE_EVT.TIME_STAMP
Diagnostics/Alerts | | UPDATE_EVT.STATIC_REVISION
| BLOCK_ERR | | UPDATE_EVT.RELATIVE_INDEX
| Alert Parameters Others
| BLOCK_ALM | SIMULATE
| | BLOCK_ALM.UNACKNOWLEDGED | GRANT_DENY
| | BLOCK_ALM.ALARM_STATE | | GRANT_DENY.GRANT
| | BLOCK_ALM.TIME_STAMP | | GRANT_DENY.DENY
| | BLOCK_ALM.SUB_CODE Query Device
| | BLOCK_ALM.VALUE Standard parameters
* Parameters not covered by category
Block Header
ST_REV
Process Value
|
|
