A-32

IM 11M12D01-61E

(13) LinkScheduleListCharacteristicsRecord

(14) DlmeScheduleDescriptor
This parameter exists for the same number as the total number of domains, and each describes the

LAS schedule downloaded to the corresponding domain. For the domain to which a schedule has not

yet been downloaded, the values in this parameter are all zeros.

(15) Domain
Read/write: impossible; get-OD: possible Carrying out the GenericDomainDownload command from a

host writes an LAS schedule to the domain.

Element

Description

Sub-

index

Size

[bytes]

2

4

2

Indicates the version number of the LAS schedule downloaded

to the corresponding domain.
Indicates the macro cycle of the LAS schedule downloaded to

the corresponding domain.
Indicates the time resolution that is required to execute the

LAS schedule downloaded to the corresponding domain.

Version


Macrocycle Duration


TimeResolution

1


2


3

TA0614.ai

Element

Description

Sub-

index

Size

[bytes]

1

1

2
2

6

Indicates the total number of LAS schedules that have been

downloaded to the domain.
Indicates the maximum number of sub-schedules an LAS

schedule can contain. (This is fixed to 1 in the Yokogawa

communication stacks.)
Indicates the version number of the schedule currently executed.
Indicates the index number of the domain that stores the

schedule currently executed.
Indicates the time when the current schedule began being

executed.

NumOf Schedules


NumOfSub SchedulesPer

Schedule


ActiveSchedule Version
ActiveSchedule OdIndex


ActiveSchedule StaringTime

1

2

3
4

5

TA0613.ai
