A-30
IM 11M12D01-61E
(5) MaxTokenHoldTimeArray
An 8- by 64-byte array variable, in which each set of 2 bytes represents the delegation time (set as an
octet time) assigned to a device. The delegation time denotes a time period that is given to a device
by means of a PT message sent from the LAS within each token circulation cycle.
The leading 2 bytes correspond to the device address 0x00, and the final 2 bytes to the device
address 0xFF. Specify the subindex to access this parameter.
(6) BootOperatFunctionalClass
Writing 1 to this parameter in a device and restarting the device causes the device to start as a basic
device. On the contrary, writing 2 to this parameter and restarting the device causes the device to
start as an LM.
(7) CurrentLinkSettingRecord and ConfiguredLinkSettingsRecord
CurrentLinkSettingRecord indicates the bus parameter settings currently used.
ConfiguredLinkSettingsRecord indicates the bus parameter settings to be used when the
device becomes the LAS. Thus, when a device is the LAS, its CurrentLinkSettingRecord and
ConfiguredLinkSettingsRecord have the same values.
(8) DlmeBasicInfo
Element
Sub-
index
Descrip-
tion
Size
[bytes]
2
1
1
1
2
1
1
1
1
1
1 V(ST)
V(PhLO)
V(MRD)
V(FUN)
V(TL)
V(MID)
V(NUN)
V(PhPE)
V(PhGE)
V(PhIS)
V(TSC) SlotTime
PerDlpduPhlOverhead
MaxResponseDelay
FirstUnpolledNodeId
ThisLink
MinInterPduDelay
NumConsecUnpolledNodeId
PreambleExtension
PostTransGapExtension
MaxInterChanSignalSkew
TimeSyncClass 1
2
3
4
5
6
7
8
9
10
11
TA0608.ai
Element Description
Sub-
index
Size
[bytes]
2
1
1
1
2
1
1
1
1
1 Indicates the capability value for V(ST) of the device.
V(PhLO)
Indicates the capability value for V(MRD) of the device.
V(TN), node address
V(TL), link-id
Indicates the capability value for V(MID) of the
device.
Indicates the capability value for V(TSC) of the device.
V(PhPE)
V(PhGE)
V(PhIS)
SlotTime
PerDlpduPhlOverhead
MaxResponseDelay
ThisNode
ThisLink
MinInterPduDelay
TimeSyncClass
PreambleExtension
PostTransGapExtension
MaxInterChanSignalSkew 1
2
3
4
5
6
7
8
9
10
TA0609.ai
