A-1
IM 11M12D01-61E
APPENDIX 1. LIST OF PARAMETERS FOR
EACH BLOCK OF AV550G
Note: The Write Mode column contains the modes in which each parameter is write enabled.
O/S: Write enabled in O/S mode.
MAN: Write enabled in Man mode and O/S mode.
AUTO: Write enabled in Auto mode, Man mode, and O/S mode.
A1.1 Resource Block
TA0101-1.ai
AUTO —
Relative
Index
Index Parameter Name Factory Default
Write
Mode
Explanation
Information on this block such as Block Tag, DD Revision,
Execution Time etc.
The revision level of the static data associated with the
resource block. The revision value is incremented each
time a static parameter value in this block is changed.
The user description of the intended application of the
block.
The strategy field can be used to identify grouping of
blocks. This data is not checked or processed by the
The identification number of the plant unit. This
information may be used in the host for sorting alarms,
etc.
The actual, target, permitted, and normal modes of the
block.
This parameter reflects the error status associated with the
hardware or software components associated with a block.
It is a bit string, so that multiple errors may be shown.
State of the resource block state machine.
Read/write test parameter-used only for conformance
testing and simulation.
String identifying the tag of the resource which contains the
Device Description for this resource.
Manufacturer identification number-used by an interface
device to locate the DD file for the resource.
Manufacturer’s model number associated with the
resource-used by interface devices to locate the DD file for
the resource.
Manufacturer revision number associated with the
resource-used by an interface device to locate the DD file
for the resource.
Revision of the DD associated with the resource-used by
an interface device to locate the DD file for the resource.
Options for controlling access of host computer and local
control panels to operating, tuning and alarm parameters
of the block.
The types of hardware available as channel numbers.
bit0: Scalar input
bit1: Scalar output
bit2: Discrete input
bit3: Discrete output
Block Tag
= O/S
AUTO
AUTO
AUTO
AUTO
AUTO
TAG: “RS” Block Header 1000 0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1001
1002
1003
1004
1005
1006
1007
1008
1009
1010
1011
1012
1013
1014
ST_REV
TAG_DESC
STRATEGY
ALERT_KEY
MODE_BLK
BLOCK_ERR
RS_STATE
TEST_RW
DD_RESOURCE
— —
(Spaces)
1
0x594543
1
—
0 —
— —
0
(Spaces) —
—
—
—
—
0x401
1
1
AUTO —
—
MANUFAC_ID
DEV_TYPE
DEV_REV
DD_REV
GRANT_DENY
HARD_TYPES 0x0001
(Scalar input)
1015
