<8. GENERAL SPECIFICATIONS>

8-2

IM 11M12D01-61E

2. Averaging Converter

Setting When Shipped.

* The tag number, if specified, will be written to the amplifier memory and inscribed on the stainless

steeltag plate.

· A tag number of up to 32 characters of alphanumerics, hyphens (-), and bullets (·) can be written to

the amplifier memory.

· A tag number of up to 16 characters of alphanumerics, hyphens (-), and bullets (·) can be

inscribed on the stainless steel tag plate (only for models with option code /SCT specified;

see GS 11M12D01- 01E).

Model

AV550G

Base

(*1)

Number of Channel

Card (*2)

Display

Options

Power supply

Communication

Option

Code

Suffix Code

-A

-B

-A1

-A2

-A3

-A4

-A5

-A6

-A7

-A8

-B1

-B2

-B3

-B4

-B5

-B6

-B7

-B8

-J

-E

-F

-G

-1

-2

-E

-F

Stainless steel tag plate

24 Voltage output for Solenoid valve

Cable gland (Numbers in )

/SCT

/24

/G

Specification

Averaging Converter
4 Channel Base

8 Channel Base

1

Oxygen Channel Card, Common Isolation

2

Oxygen Channel Cards, Common Isolation

3

Oxygen Channel Cards, Common Isolation

4

Oxygen Channel Cards, Common Isolation

5

Oxygen Channel Cards, Common Isolation

6

Oxygen Channel Cards, Common Isolation

7

Oxygen Channel Cards, Common Isolation

8

Oxygen Channel Cards, Common Isolation

1

Oxygen Channel Card, Individual Isolation

2

Oxygen Channel Cards, Individual Isolation

3

Oxygen Channel Cards, Individual Isolation

4

Oxygen Channel Cards, Individual Isolation

5

Oxygen Channel Cards, Individual Isolation

6

Oxygen Channel Cards, Individual Isolation

7

Oxygen Channel Cards, Individual Isolation

8

Oxygen Channel Cards, Individual Isolation

Japanese

English

French

German
100 / 115 V AC

230 V AC
HART communication

FOUNDATION Fieldbus communication

T03.ai

(*5)

(*3)

(*1)

Select code "-B" (8 Channel Base)when future expansion exceeding 4 channels is expected.

By so doing, the expansion can be made economically.

(*2)

Common isolation is recommended, when the same instrument receives the analog

outputs from each channel card. Individual isolation is recommended to prevent the

trouble by mutual interference, when different instrument receives the analog outputs

from each channel card.

(*5)

Input 01 to 30 in

.

(*3)

When suffix code "-2" (230 V AC) is selected, select code "-A" (4 Channel Base).

(*4)

When suffix code "-F" (FOUNDATION Fieldbus communication) is selected, used exclusively

for communication.

(*4)

T02.ai

Upper Limit : 100

Lower Limit : 0

Unit : %

Tag number* (PD_TAG)
Output mode (L_TYPE)
Upper and lower calculation range limits

and unit (XD_SCALE)
Upper and lower output range limits and

unit (OUT_SCALE)
Node address

Set to “AV550G” by default unless otherwise specified when ordered.

“Direct”

Set to 0xF7 unless otherwise specified when ordered.

Oxygen concentration (AI)

Item
