<7. DEVICE STATUS>
7-1
IM 11M12D01-61E
7. DEVICE STATUS
In an AV550G, resource block parameters DEVICE_STATUS_1 through DEVICE_STATUS_4 (with
indexes 1045 through 1048) represent alarm and error statuses:
Table 7.1 Contents of DEVICE_STATUS_1 (Index 1045)
Table 7.2 Contents of DEVICE_STATUS_2 (Index 1046)
Table 7.3 Contents of DEVICE_STATUS_3 (Index 1047)
Hexadecimal
Representation
Reading when DD Is Downloaded Description
0x02000000 Download fail
0x01000000 Download incomplete
0x00800000 Simulate enable switch On
0x00400000 RB in O/S mode Shows that the resource block is in the O/S mode.
0x00080000 AMP module failure 1 Shows that the amplifierís EEPROM is faulty.
0x00008000 Link Obj. 1/17/33 not open Shows that the VCR specified in Link Object 1 is not open.
0x00004000 Link Obj. 2/18/34 not open Shows that the VCR specified in Link Object 2 is not open.
0x00002000 Link Obj. 3/19/35 not open Shows that the VCR specified in Link Object 3 is not open.
0x00001000 Link Obj. 4/20/36 not open Shows that the VCR specified in Link Object 4 is not open.
0x00000800 Link Obj. 5/21/37 not open Shows that the VCR specified in Link Object 5 is not open.
0x00000400 Link Obj. 6/22/38 not open Shows that the VCR specified in Link Object 6 is not open.
0x00000200 Link Obj. 7/23/39 not open Shows that the VCR specified in Link Object 7 is not open.
0x00000100 Link Obj. 8/24/40 not open Shows that the VCR specified in Link Object 8 is not open.
0x00000080 Link Obj. 9/25 not open Shows that the VCR specified in Link Object 9 is not open.
0x00000040 Link Obj. 10/26 not open Shows that the VCR specified in Link Object 10 is not open.
0x00000020 Link Obj. 11/27 not open Shows that the VCR specified in Link Object 11 is not open.
0x00000010 Link Obj. 12/28 not open Shows that the VCR specified in Link Object 12 is not open.
0x00000008 Link Obj. 13/29 not open Shows that the VCR specified in Link Object 13 is not open.
0x00000004 Link Obj. 14/30 not open Shows that the VCR specified in Link Object 14 is not open.
0x00000002 Link Obj. 15/31 not open Shows that the VCR specified in Link Object 15 is not open.
0x00000001 Link Obj. 16/32 not open Shows that the VCR specified in Link Object 16 is not open.
Shows that the software downloading state is 0Fail.0
Shows that the software downloading state is 0Incomplete.0
Shows that the SIMULATE_ENABLE switch is 0ON.0
Hexadecimal
Representation
Reading when DD Is Downloaded Description
0x00000002 COM. Circuit failure 1 Shows that the amplifierís communication circuit block is faulty (1).
0x00000001 COM. Circuit failure 2 Shows that the amplifierís communication circuit block is faulty (2).
Hexadecimal
Representation
Reading when DD Is Downloaded Description
0x01000000 Transducer Block in O/S mode Shows that the transducer block is in the O/S mode.
0x00800000 AI Function Block 1 not scheduled Shows that AI function block 1 is not yet scheduled.
0x00400000
Simulation is enabled in AI Function
Block 1
Shows that AI function block 1 is in a SIMULATE state.
0x00200000 AI Function Block 1 in Manual mode Shows that AI function block 1 is in the Manual mode.
0x00100000 AI Function Block 1 in O/S mode Shows that AI function block 1 is in the O/S mode.
0x00040000 AI Function Block 2 not scheduled Shows that AI function block 2 is not yet scheduled.
0x00020000
Simulation is enabled in AI Function
Block 2
Shows that AI function block 2 is in a SIMULATE state.
0x00010000 AI Function Block 2 in Manual mode Shows that AI function block 2 is in the Manual mode.
0x00008000 AI Function Block 2 in O/S mode Shows that AI function block 2 is in the O/S mode.
0x00002000 AI Function Block 3 not scheduled Shows that AI function block 3 is not yet scheduled.
0x00001000
Simulation is enabled in AI Function
Block 3
Shows that AI function block 3 is in a SIMULATE state.
0x00000800 AI Function Block 3 in Manual mode Shows that AI function block 3 is in the Manual mode.
0x00000400 AI Function Block 3 in O/S mode Shows that AI function block 3 is in the O/S mode.
0x00000100 DI Function Block 1 not scheduled Shows that DI function block 1 is not yet scheduled.
0x00000080
Simulation is enabled in DI Function
Block 1
Shows that DI function block 1 is in a SIMULATE state.
0x00000040 DI Function Block 1 in Manual mode Shows that DI function block 1 is in the Manual mode.
0x00000020 DI Function Block 1 in O/S mode Shows that DI function block 1 is in the O/S mode.
0x00000008 DI Function Block 2 not scheduled Shows that DI function block 2 is not yet scheduled.
0x00000004
imulation is enabled in DI Function
Block 2
Shows that DI function block 2 is in a SIMULATE state.
0x00000002 DI Function Block 2 in Manual mode Shows that DI function block 2 is in the Manual mode.
0x00000001 DI Function Block 2 in O/S mode Shows that DI function block 2 is in the O/S mode.
