Silver Series OIT

 5 

Watlow Addendum

• The IP address is listed in the System settings window on the Network tab. (If Auto Get IP

Address is selected, the IP Address is not editable. If you want to configure the OIT for a fixed
address, select IP address get from below, and enter the IP address here.

• Click OK to close the System settings window on the OIT.

Hints for using the Virtual Keyboard to enter the OIT password and IP addresses:

• If you do not see the Virtual Keyboard it may be minimized; click the X on the menu bar.
• Make sure the cursor is in the Password or IP address field on the System Settings dialog.
• Enter the password by clicking only the keys on the Virtual keyboard. If you click the caption

bar or other part of the Virtual keyboard window, your keystrokes are not entered in the System
Settings
dialog.

• You can tell the password key strokes are being entered if you hear the key chirp from the OIT

and see stars (******) appearing in the password field.

• If you cannot see the Password field, arrange the Virtual Keyboard and System Settings

dialog then make sure the cursor is in the Password field.

• If you are entering the password on the Virtual Keyboard but stars aren’t appearing in the

Password field, make sure the Password field has focus. If you do not see the text insertion
cursor ( | ) in the Password field, it does not have focus. Click in the Password field to give it
focus then click keys, but nothing else on the Virtual Keyboard.

• One you have entered the password and the stars appear in the Password field, you can minimize

the Virtual Keyboard by clicking the minimize button at the upper right corner to access the
check boxes and buttons on the System Settings dialog.

Chapter 3: Communications
Basics

The Silver Series OIT can communicate with Watlow controllers via Modbus TCP or Modbus RTU.
This section defines terms you will encounter and provides information about Modbus communications
that will help you create a user interface with the Silver Series OIT for equipment and machines that
include Watlow controllers.

About Gateways, Controllers and PLCs

The Silver Series OIT can communicate with a variety of devices. Because many of these devices are
Programmable Logic Controllers (PLCs), EasyBuilder5000 refers to devices in many places generically
as “PLCs”. Don’t let this confuse you. When you are setting up the OIT to communicate with a Watlow
product, from the OIT’s point of view the controller is a PLC.

This addendum refers to configuring the Silver Series OIT to communicate with “controllers”, but the
instructions apply equally to limit controllers and gateways such as the EZ-ZONE

®

RUI Gateway.

3
