Silver Series OIT  23  Watlow Addendum
8) In the Values column
type the numeric and
text values that
corresponds to each
option you want to
include. See the table.
9) Click OK to close the
New Option List
Object dialog. (020)
State Value Enumerated Value
0 10 Auto
1 54 Manual
2 62 Off
3 (error)
10) Position the cursor
near the bottom center
of the window layout
and click to place the
multi-state switch.
(You may have to
move the other objects
around to fit
everything.)
11) From the File menu
choose Save.
(022)
