LT-4201TM/4301TM Hardware Manual
83
USB Data Transfer Cable - USB Driver Installation
Important Information
Follow these instructions to avoid damage to the cable connector or the unit:
Do not connect the USB data transfer cable until told to do so in the instructions.
Insert the connector at the correct angle when connecting the USB data transfer cable to the
PC or to the unit.
Hold the connector, not the cable itself when disconnecting the cable.
Use the port designated during installation. If the cable is unplugged from the port designated
during installation and connected to a different port, the Operating System (OS) does not
recognize the new port.
Restart the PC and quit all resident applications before reinstalling the software if the installation
does not complete successfully.
NOTE: For transfer methods, refer to the following manual: GP-Pro EX Reference Manual
"Transferring project files via USB transfer cable".
USB Host Interface Characteristics
USB (Type A) Interface
USB (mini-B) Interface
Connector
USB 2.0 (Type A) x 1
USB 2.0 (mini-B) x 1
Power Supply Voltage
5 Vdc ± 5%
–
Maximum Current Supplied
500 mA
–
Maximum Transmission Distance
5 m (16.4 ft)
