Proface LT4300M - 5.7 Modular HMI + Control" User Manual
Page 62
LT Installation
62
Dimensions
NOTE: With the tee option, the display module supports a rotating torque of 6 N•m (53.10 lb-in).
Installing the LT Display
The figure shows the assembly:
(1) Display module
(2) Panel
(3) Display installation nut
(4) Anti-rotation tee
C
D
30
0/-0.20
mm
(1.18
0/-0.0007
in.)
4
0/-0.20
mm
(0.15
0/-0.007
in.)
