Page 35: 2 display specifications 2.2.3

GP3000H Series Hardware Manual
2-6
2.2.2
Display Specifications
2.2.3
Touch Panel Specifications
AGP-3300HL
AGP-3300HS
AGP-3310HT
Display Type
Monochrome LCD
STN Color LCD
TFT Color LCD
Resolution
W 320 X H 240 pixels
W 640 X H 480 pixels
Dot pitch
W 0.36 mm [0.01 in.] X H 0.36 mm [0.01 in.]
W 0.18 mm [0.01 in.] X
H 0.18 mm [0.01 in.]
Effective Display
Area
W 117.2 mm [4.61 in.] X H 88.4 mm [3.48 in.]
W 115.2 mm [4.54 in.] X
H 86.4 mm [3.40 in.]
Color/Shade level
Black and White
(16 Shades)
4,096 Colors
65,536 Colors
(No blink)
16,384 Colors
(With blink enabled)
Backlight
White LED
(Not user replaceable. When replacement is required, contact your local GP
distributor.)
Brightness control
16 levels of adjustment available via touch panel
Contrast Adjustment 8 levels of adjustment available via touch panel
Not applicable
Backlight Service
Life
50,000 hours or more
(at 25°C and continuous operation - period until
backlight brightness decreases to 50% or backlight starts to flicker)
Language Fonts
Japanese: 6962 (JIS Standards 1 & 2) (including 607 non-kanji characters)
ANK: 158 (Korean, Traditional Chinese and Simplified Chinese fonts are
downloadable.)
Te
xt co
mposition
Character Sizes
Standard font: 8 X 8, 8 X 16, 16 X 16 and 32 X 32 dot fonts
Stroke font: 6 to 127 dot fonts
Font Sizes
Standard font: Width can be expanded up to 8 times.
Height can be expanded up to 8 times
*1
*1 The other font sizes can be set up by software.
Te
xt
8 X 8 dots
40 Char. X 30 rows
80 Char. X 60 rows
8 X 16 dots
40 Char. X 15 rows
80 Char. X 30 rows
16 X 16 dots
20 Char. X 15 rows
40 Char. X 30 rows
32 X 32 dots
10 Char. X 7 rows
20 Char. X 15 rows
Type
Resistive Film (analog)
Resolution
1024 X 1024
Service Life
1,000,000 times or more
