Proface AGP3500 - 10.4 DIO HMI" User Manual
Page 17
GP3000H Series Hardware Manual
1-4
Mitsubishi PLC A, QnA,
FX Series' 2 Port Adapter II
GP070-MD11
2 Port
Adapter Cable
CA3-MDCB11
RS-422 Cable
(Prepared by user)
Multi-Link Cable
CA3-CBLMLT-01
Terminal Block
Conversion Adapter
CA3-ADPTRM-01
COM Port
Conversion
Adapter
CA3-ADPCOM-01
RS-422 Cable
CA3-CBL422/5M-01
RS-422 Cable
CA3-CBL422-01
Host Controller
PLC etc.
Mitsubishi PLC
FX-Series Connection Cable
CA3-CBLFX/1M-01
CA3-CBLFX/5M-01
(11)
(11)
(11)
(9)
(9)
(9)
(6)
(3)
(7)
Mitsubishi PLC
A-Series Connection Cable
CA3-CBLA-01
MPI Cable
ST03-A2B-MPI21-PFE
(10)
Continued from
GP3000H Conversion Adapter
To an Ethernet Network
Twisted pair Cable
(Commercial type)
HUB
(Commercial type)
Continued
GP Unit – Continued from
the GP3000H Cable Connector
