Chapter 2 Specifications
2-5
*1 User active capacity.
*2 When using the GP3000H Conversion Adapter, the distance includes the length of
cable between the GP and the Conversion Adapter.
*3 Overall system may not meet these standards if implemented outside these
parameters.
Be sure to follow these standards when designing the system.
*4 To use GP's external output interface eg. DOUT and build a system, Pro-face's
dedicated Cable with Connector and Conversion Adapter (AGP3000H-ADPCOM-
01) (separately sold) are required.
• For the details of DOUT circuit diagram, etc..., please see "GP3000H Conversion
Adapter Installation Guide" (Included with the Conversion Adapter)
• For the kinds of the dedicated Cable with Connector, please see "1.2 Accessories
1.2.1 GP3000H Cable Connector (page1-8)"
*5 The GP's internal clock has a slight error. At normal operating temperatures and
conditions, with the GP operating from its lithium battery, the degree of error is 65
seconds per month. Variations in operating conditions and battery life can cause this
error to vary from -380 to +90 seconds per month. For systems where this degree of
error will be a problem, the user should be sure to monitor this error and make
adjustments when required.
•
When the message “RAAA051 Low battery” is displayed, supply power to the display unit and
fully charge the battery. The battery charges within 24 hours to a level which allows backup
operation. Completing a full charge requires about 96 hours (4 days).
•
A Lithium battery’s lifetime is: 10 years when the battery’s ambient temperature is 40°C or less.
4.1 years when the battery’s ambient temperature is 50°C or less. 1.5 years when the battery’s
ambient temperature is 60°C or less.
When used for backup:
Approximately 100 days, with a fully charged battery.
Approximately 6 days, with a half-charged battery.
•
When connecting the external device directly to the GP unit with an Ethernet cable, depending
on the external device, communication may not be possible.
Please connect over a network hub.
