GP3000H Series Hardware Manual
2-4
2.2
Performance Specifications
2.2.1
Performance Specifications
Application
*1
AGP-3300HL/AGP-3300HS: FLASH EPROM 6 MB
AGP-3310HT: FLASH EPROM 8 MB
Data Backup
SRAM 320 KB (Used lithium battery for backup memory)
GP30
00H Cab
le Con
nector
Serial Interface
RS-232C/RS-422/RS-485
Asynchronous Transmission:
Data Length: 7 bit/8 bit
Parity: none, Odd or Even
Stop Bit: 1 bit/2 bit
Data transmission Speed:2400 bps to 115.2 kbps
187.5 kbps (MPI)
Maximum communication distance
*2
:
15 m (when using RS-232C),
1200 m (when using RS-422 at 115.2 kbps)
Ethernet Interface
Ethernet (IEEE802.3u,10BASE-T/100BASE-TX)
Maximum communication distance
*2
: 100 m
Emergency Switch Output
Interface
Push-lock switch
3 contacts; a-contact (normally open): 1contact,
b-contact (normally closed): 2 contacts
Rated voltage: DC30V
Maximum rated current: 1 A
(Minimum allowable load: DC5V, 1 mA)
Applicable standards
*3
:
ICE60947-5-1, EN60947-5-1, ICE60947-5-5, EN60947-5-5,
UL508, CSA C22.2 No.14
3-Position Enable Switch
Output Interface
GP Rear panel switch
2 contacts (a-contact: normally open)
Rated voltage: DC30V
Maximum rated current: 700mA
(Minimum allowable load: DC3V, 5 mA)
Applicable standards
*3
IEC60947-5-8, EN60947-5-8, UL508 (UL approval),
CSA C22.2 No.14 (UL approval),
ISO12100/EN12100-1,2, IEC60204-1/EN60204-1
ISO11161/prEN11161, ISO10218/EN775,
ANSI/RIA R15.06, ANSI B11.19
Key Switch Output
Interface
1c-contact (can be set normally open or normally closed.)
Rated voltage: DC24V
Maximum rated current: 300 mA
External
Output
I/F
*4
DOUT Output
Open Collector Output: 2 points (GP Front function switches,
F1 and F2 keys)
Rated Voltage: DC24V
Rated Current: 300 mA/point max.
Operation Output
Open Collector Output: 1 point
Rated Voltage: DC24V
Rated Current: 300 mA max.
External Buzzer Output
Open Collector Output 1 point
Rated Voltage: DC24V
Rated Current: 300 mA max.
USB Host Interface
Conforms to USB1.1. (TYPE-A connector) x 1
Power Supply Voltage: DC5V
±
5%
Output Current: 500 mA (max.)
Communication Distance: 5 m (max.)
CF Card Interface
Compact Flash CF Card Slot (TYPE-II)
Clock Accuracy
*5
±
65 seconds/month (at room temperature)
