32
IBTracer 4X Protocol Analyzer User’s Manual CATC SW Version 2.3
Search
Go to Trigger Positions the display to the first packet following the trigger event.
Go to
Packet/Operation/
MAD... Positions the display to the indicated packet, Operation, or MAD.
Go to Marker » Positions the display to a previously marked packet.
Go to » Enables searching for specific events using a cascade of pop-up menus.
Find Allows complex searches.
Find Next Repeats the previous Find operation. Also use F3 to find next.
Search Direction Allows you to specify a forward or backward search of a trace file.
View
Toolbars Displays list of available toolbars. Has a customize command for
creating.
Status Bar Switches display of the Status Bar on or off.
Real-Time Statistics Allows viewing of statistical data as it happens.
Expand Allows field headers to be expanded.
Collapse Allows packet headers to be collapsed.
Show/Hide Allows different types of packets to be hidden or displayed.
Compound
Show/Hide Lets you selectively show or hide multiple items from the trace.
Zoom In Zoom in increases the size of the displayed elements.
Zoom Out Zoom out decreases the size of the displayed elements.
Wrap Allows the display to wrap.
Decoding
Assignments Opens a dialog box for creating or editing protocol assignments to
connections.
Resolve Reliable
Connections Opens a dialog box for resolving Unresolved Reliable connections
within the open trace.
Packets Level View packet level.
Transport Functions
Level View/Hide Transports Functions Level.
MADs Level View/Hide MADs Level.
SADM Level View/Hide Subnet Administration Level.
SDP Level View/Hide Sockets Direct Protocol Level.
SRP Level View/Hide SCSI RDMA Level.
Menu Function
