21
IBTracer 4X Protocol Analyzer User’s Manual CATC SW Version 2.3
Step 2
Cause the device under test to generate InfiniBand traffic.
Step 3 Click on the Tool Bar.
After 16 Mbytes of traffic is recorded, the analyzer will upload the
data and display the packets.
To terminate the recording before Inquiry timeout occurs,
Step 4 Click on the Tool Bar at any time before recording
automatically terminates.
When the recording session is finished, the traffic is saved to the
hard drive as a file named data.ibt or whatever name you assign as
the default filename.
To save a current recording for future reference,
Step 5 Select Save As under File on the Menu Bar.
OR
Click on the Tool Bar.
You see the standard Save As screen.
Step 6 Give the recording a unique name and save it to the appropriate
directory.
