65

Electronics

X96-2001PL

X96-2001PL is a CPU Module that comes without software.

X96-2002PL

X96-2002PL is the local Graphics L.C.D. Module. This optional module provides:
• Graphic LCD

• Keypad

X96-2003PL

X96-2003PL is the Ionization Chamber Interface Module. This optional

3

module provides:

• 1 ionization detector input

• 1 feedback input for ionization detector

• 1 head temperature input
• 1 non-isolated RTD (3-wire) input (stuffing option)

• Power

4

for the ionization detector (15 volts at 35 ma and –15 volts at 5 ma).

X96-2004PL

X96-2004PL is the 2-Channel Analog Output Module. This optional module has two isolated analog outputs
each of which can be independently configured as a:
• 4-20 mA current loop,

• a source of 0 to 10 volts, or
• a sink of 0 to 20 ma.

X96-2005PL

X96-2007PL is the HART Daughter Module. This module provides both a 4-20 mA current loop and a
HART slave interface.

3

At least one detector interface module is required.

4

The power supply has the ability to control power to the ionization detector:

• when commanded by the CPU module,

• when the watchdog timer generates a reset.
