22
ITEM FUNCTION
Temp Units Shows and allows the user to set the units to be used for process temperature
Low Range Shows and allows the user to set the temperature value to be mapped to 4ma on the
current loop output, if process temperature is selected to control that current loop.
High Range Shows and allows the user to set the temperature value to be mapped to 20ma on the
current loop output, if process temperature is selected to control that current loop.
Temp Units is one of the following:
ITEM MEANING
Deg C degrees Celsius
Deg F degrees Fahrenheit
Deg R degrees Rankine
Kelvin degrees Kelvin
Head Temp
The Head Temp Config menu is used to configure the parameters associated with the detector electronics temperature
measurement. This function is used primarily in high-temperature applications where the temperature exceeds the electronics
temperature specifications. It contains the following items:
ITEM FUNCTION
Temp Units Shows and allows the user to set the units to be used for head temperature
Low Range Shows and allows the user to set the temperature value to be mapped to 4ma on the
current loop output, if head temperature is selected to control that current loop.
High Range Shows and allows the user to set the temperature value to be mapped to20ma on the
current loop output, if head temperature is selected to control that current loop.
Temp Units is one of the following:
ITEM MEANING
Deg C Degree Celsius
Deg F Degree Fahrenheit
Deg R Degree Rankine
Kelvin Kelvin
Display Totalizer
The Display Totalizer menu is used to configure the parameters associated with the Display Totalizer. It contains the following
items:
ITEM FUNCTION
Totalizer Shows the accumulated mass flow in the Total Mass Flow register
Elapsed Time Shows the elapsed time since the last time the Totalizer was reset.
Totalizer Units Shows and allows the user to set the units to be used for the Totalizer.
Ext Reset Shows and allows the user to enable/disable the Totalizer to be reset remotely
Cutoff Shows and allows the user to set the minimum percent of material before totalization
occurs
Reset Totalizer Shows and allows the user to reset the Totalizer locally
Totalizer Units is one of the following:
UNITS MEANING
Ston Short Tons
LTon Long Tons
lb pounds
ounce ounces
MetTon Metric Tons
kg kilograms
g grams
