32
Cal Flow Rate Menu
This menu is used to access the various flow rate calibration procedures. It contains the following items:
ITEM FUNCTION
State Shows the state of the flow rate configuration process
Low Reference Selecting this item takes the user to the Low Reference menu
High Calibrate Selecting this item takes the user to the High Calibrate menu
Manual Entry Shows and allows the user to set the calculated Pulse Factor value
Clear Ref/Cal This item invokes method that clears the mass flow reference and pulse factor
Ref/Cal Time Shows and allows the user to set the number of seconds of data to collect for a
reference or calibrate sample
Flow Rate Deviation Shows and allows the user to set the percent of deviation of the current counts
during calibration
Low Reference (Cal Flow Rate)
This menu is used to reference the minimum flow rate value.
ITEM FUNCTION
Low Flow Rate Cal This item invokes a method that performs the low flow rate reference
Low Flow Rate This item shows and allows the user to set the minimum flow rate
Ref. Capt. Value This item shows the captured low flow rate counts
High Calibrate (Cal Flow Rate)
This menu is used to calibrate the maximum flow rate value.
ITEM FUNCTION
High Flow Rate Cal This item invokes a method that performs the high flow rate calibration
High Flow Rate This item shows and allows the user to set the maximum flow rate
Cal. Capt. Value This item shows the captured maximum flow rate counts
Pulse Factor Shows the user the calculated pulse factor value (read only – multiplier)
Manual Entry (Cal Flow Rate) Menu
ITEM FUNCTION
Pulse Factor Shows and allows the user to set the Pulse per flow rate (L/s) value (multiplier)
Fixed Flow Rate Shows and allows the user to set the fixed flow rate value
