28
System
The System menu is used to provide information about the X96S. It contains the following items:
ITEM MEANING
Serial # Shows the device serial number
Hardware Rev Shows the number of device hardware revisions
Software Rev Shows the number of device software revisions
Date Shows and allows the user to set the date
Hour (0-23) Shows and allows the user to set the hour
Minute Shows and allows the user to set the minute
Password Shows and allows the user to set a password from the main display to allow access to
all menus
Date/Time Format Shows and allows the user to set the date/time format used on the status display
Date/Time Format is one of the following:
ITEM MEANING
mm/dd/yy hh:mm:ss North American date and 24 hour time
mm/dd/yyyy hh:mm:ss North American Y2K date and 24 hour time,
mm/dd/yy hh:mm:ss am/pm North American date and 12 hour time with am/pm indication
dd-mm-yy hh:mm:ss European date and 24 hour time,
dd-mm-yyyy hh:mm:ss European Y2K date and 24 hour time
dd/mm/yy hh:mm:ss European date and 24 hour time
dd/mm/yyyy hh:mm:ss European Y2K date and 24 hour time
Digital Outputs Menu
This menu is used to view and configure the digital outputs. It contains the following items:
ITEM FUNCTION
Output Shows and allows the user select and configure a specific digital output (Relay 1-4 or
TTL 1-4)
Select Sources Selecting this allows the user to assign an array of sources to the above digital output
Polarity Shows and allows the user to set the above digital output
